Scheda tecnica
| Larghezza | Spessore in mm | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 | 4 | 5 | 6 | 8 | 10 | 12 | 15 | 20 | 25 | 30 | 35 | 40 | 50 | |
| 10 | 0,236 | 0,314 | 0,393 | 0,471 | ||||||||||
| 15 | 0,353 | 0,471 | 0,589 | 0,707 | 0,942 | 1,178 | ||||||||
| 20 | 0,471 | 0,628 | 0,785 | 0,942 | 1,256 | 1,57 | 1,844 | 2,355 | ||||||
| 25 | 0,589 | 0,785 | 0,981 | 1,178 | 1,57 | 1,963 | 2,355 | 2,944 | 3,925 | |||||
| 30 | 0,707 | 0,942 | 1,178 | 1,413 | 1,884 | 2,355 | 2,826 | 3,533 | 4,71 | 5,888 | ||||
| 35 | 0,824 | 1,099 | 1,374 | 1,649 | 2,198 | 2,748 | 3,297 | 4,121 | 5,495 | 6,869 | ||||
| 40 | 0,942 | 1,256 | 1,57 | 1,884 | 2,512 | 3,14 | 3,768 | 4,71 | 6,908 | 7,85 | 9,42 | |||
| 45 | 1,06 | 1,413 | 1,766 | 2,826 | 3,533 | 3,533 | 4,239 | 5,299 | 7,065 | 8,831 | 10,6 | 13,74 | 15,7 | |
| 50 | 1,177 | 1,57 | 1,962 | 2,355 | 3,14 | 3,925 | 4,71 | 5,888 | 7,85 | 9,813 | 11,77 | 16,48 | 18,84 | |
| 60 | 1,413 | 1,884 | 2,355 | 2,826 | 3,768 | 4,71 | 5,652 | 7,065 | 9,42 | 11,77 | 14,3 | 19,23 | 21,98 | 27,48 |
| 70 | 1,649 | 2,198 | 2,748 | 3,297 | 4,396 | 5,495 | 6,594 | 8,243 | 10,99 | 13,74 | 16,49 | 21,98 | 25,12 | 21,4 |
| 80 | 1,884 | 2,512 | 3,14 | 3,768 | 5,024 | 6,28 | 7,536 | 9,42 | 12,56 | 15,7 | 18,84 | 28,26 | 35,32 | |
| 90 | 5,532 | 4,239 | 5,652 | 7,065 | 8,478 | 10,6 | 14,13 | 21,2 | 27,47 | 31,4 | 39,25 | |||
| 100 | 3,925 | 4,71 | 6,28 | 7,85 | 9,42 | 11,77 | 15,7 | 19,62 | 23,55 | 32,97 | 37,68 | 47,1 | ||
| 120 | 4,71 | 5,652 | 7,536 | 9,42 | 11,3 | 14,13 | 18,84 | 23,55 | 28,26 | 47,1 | 58,87 | |||
| 150 | 5,887 | 7,065 | 9,42 | 11,77 | 14,13 | 17,66 | 23,55 | 29,44 | 35,33 | |||||
| 200 | 7,85 | 9,42 | 12,56 | 15,7 | 18,84 | 23,55 | 31,4 | |||||||
